DOROT S80 ELD3/M (3W)

Irrigation

DOROT S80 ELD3/M (3W)

Diaphragm-actuated, Rigid Seal, 3-way Solenoid-controlled Globe Valve

DOROT S80 ELD3/M (3W), is a Diaphragm-actuated, Rigid Seal, 3-way, automatic, solenoid-controlled globe valve, with a 3-way solenoid and selector valve for manual override. The valve opens when the solenoid is energized and closes drip-tight when the solenoid is de-energized.

Go to S80 Basic Valve

Technical Specifications

Size Unit

Size range

DN20 - DN100 (¾"- 4")

Pressure rating

PN10

Working temperature

0ᵒ – 60ᵒ C

End connection type

Threaded, Flanged

Standard construction materials

Body and Cover

Reinforced Nylon

Internal Parts

Stainless Steel and Polymer

Seals + Diaphragm

EPDM

* Other optional materials available upon request

DOROT S80 ELD3/M (3W)

<img width="2000" height="2000" src="https://www.aquestia.com/wp-content/uploads/2025/01/IRG-S80A-2-BSTH-ELD3-M-3W-PP_left.jpg" alt="DOROT S80 ELD3/M (3W)">

DOROT S80 ELD3/M (3W)

<img width="2000" height="2000" src="https://www.aquestia.com/wp-content/uploads/2025/01/IRG-S80A-2-BSTH-ELD3-M-3W-PP_right.jpg" alt="">

DOROT S80 ELD3/M (3W)

DOROT S80 ELD3/M (3W)

<img width="2000" height="2000" src="https://www.aquestia.com/wp-content/uploads/2025/01/IRG-S80A-2-BSTH-ELD3-M-3W-PP_left.jpg" alt="DOROT S80 ELD3/M (3W)">

<img width="2000" height="2000" src="https://www.aquestia.com/wp-content/uploads/2025/01/IRG-S80A-2-BSTH-ELD3-M-3W-PP_right.jpg" alt="">

Features & Benefits

Built-in control system

No additional accessories to assemble or external loop; prohibits in-the-field damage by animals

3-position manual override: open/auto/closed

Independent override mechanism, not dependent on solenoid, for increased operational reliability

Exclusive labyrinth

Large inlet filter plus labyrinth; provides outstanding protection against clogging

Flow control handle with removable knob

User adjustable settings with disabler; prevents unauthorized changes or tampering once values are set

Durable corrosion-resistant materials

Constructed from high-quality materials that resist corrosion, chemicals, and UV radiation; ideal for long-term use in harsh environments

High flow capacity

Designed with large water flow capacity; ensures efficient irrigation for large-scale agricultural applications
