DOROT S300 Series

Superior Control Valve for Highly Accurate Flow & Pressure Regulation

DOROT S300 Series Diaphragm-actuated, Globe-type Control Valve, provides unmatched performance, accuracy and reliability, even for the most demanding water system requirements. This advanced Control Valve features a unique seat design to protect against high-pressure surges and water hammer, along with the exclusive Linear Throttling Plug (LTP) for precise low-flow regulation and minimal head loss.

Standout Features

Near zero flow regulation for optimal water management

Self-cleaning inline filter, flushes debris during operation

Flexible installation design for a range of configurations

Cavitation resistance flow dynamics

Exceptional durability & corrosion resistance

Handles challenging water quality

Standout Features

Near zero flow regulation for optimal water management

Self-cleaning inline filter, flushes debris during operation

Flexible installation design for a range of configurations

Cavitation resistance flow dynamics

Exceptional durability & corrosion resistance

Handles challenging water quality

Features & Benefits

1

Position indicator

Clear view of valve position status
2

Safety air release

Reliable, effective air removal from the control loop
3

Preformed diaphragm

Innovative design enhances durability, reliability & system performance
4

Can easily convert into a double-chamber

Enables versatility, & improved valve performance for specific applications
5

LTP (Linear Throttling Plug)

Unique feature for superior flow regulation & max. operational efficiency
6

Stainless Steel components: internal & external

Robust, reliable, long-term water system management solution, even in challenging applications
Downloads

Product Page (PDF)

EN

FR

ES

PT

BIM Models

Technical Specifications

Size Unit

Size range

DN40 - DN1000 (1½ - 40")

Pressure rating

PN16, PN25

Working temperature

0ᵒ – 80ᵒ C

End connection type

Threaded, Flanged, Grooved

Standard construction materials

Body and Cover

Stainless Steel

Internal Parts

Stainless Steel

Seals + Diaphragm

EPDM

* Other optional materials available upon request

Control Functions

Pressure Regulation
Flow Regulation
Level Control
Pumping Systems
On/Off
Safety
Electronic
  • Pressure Regulation
  • Flow Regulation
  • Level Control
  • Pumping Systems
  • On/Off
  • Safety
  • Electronic
DOROT S300 PR (2W)
Diaphragm-actuated, Rigid Seal, 2-way Pressure Reducing Globe Valve
DOROT S300 PS (2W)
Diaphragm-actuated, Rigid Seal, 2-way Pressure Sustaining Globe Valve
DOROT S300 PS[R]
Diaphragm-actuated, Rigid Seal, Pressure Sustaining/Relief Globe Valve
